Gartec Trolley Lift (Small Goods Lift)
A Trolley Lift (or small goods lift) is the ideal solution for middle range loads and floor level loading, bigger than the dumbwaiter, but with lower capacity than the goods lift.
A Trolley Lift (or small goods lift) is the ideal solution for middle range loads, slightly bigger than the dumbwaiter, but not as big as the goods lift. A trolley lift provides a convenient and fast way to transport trolleys, small goods, barrels, refuse and general bulky items without manual handling. Our trolley lift can be custom size, with entrance points generally at floor level.
The Gartec Trolley Lift (or small goods lift) is a simple but versatile mid-size goods lift, able to carry loads from 250 – 300kg between floors to reduce manual handling. Trolley lifts are slightly bigger than the dumb waiter, but not as big as the goods lift. The car can be custom size to your trolley dimensions, with entrance points generally at floor level. Robust push buttons and a wipe-clean finish improve trolley lift lifetime. A rapid 2-3 day installation mean you can get back to work faster. Read more about our goods lift range.
- Up to 6 floors (20m)
- Load rated 250kg – 300kg
- Hinged or Concertina Door, picket gate option available
- Self supporting steel frame
- Call and send buttons, with position indicator
- 150 – 600mm pit/ramp
The Gartec Trolley Lift uses a self-supporting frame, erected in a few days with minimal building works on site and no load bearing shaft required.
The interlocking entrances put safety first, and multiple entrance points on each floor offer convenience of access.
